CrosArc TIG 400 AC/DC 400V CAP0979

SKU: N/A
Sale!

£3,500.00 Ex. VAT£2,800.00 Ex. VAT

The CROSARC TIG 201 AC/DC is a next generation inverter based power source operating from a 230v mains supply. This industry leading machine offers incredible functionality and exceptional welding performance in a compact portable design. The CROSARC 201 AC/DC incorporate a user friendly control panel allowing the operator full adjustment of all welding parameters, making it the perfect solution for a wide range of applications.



Package includes:

  • TIG 201 AC/ DC Inverter Power Source Parker DGT26FX-12 TIG Welding Torch
  • Earth Return Lead & Clamp
  • Gas Hose
  • 3 Mtr MMA Lead
  • 16A Plug



Options:

  • Foot Pedal (CAP1043)
  • Inverter Trolley (CAP0216)



Features:

  • Latest IGBT Multi Process Inverter Power Source
  • Digital Volt / Amp Display
  • VRD Safety Device
  • Portable
  • Generator Friendly
  • Easy Set Up & Operation



Functions:

  • MMA
  • TIG AC/DC HF/LIFT
  • 2T/4T
  • Pre/Post Flow Gas Adjustment
  • Up/Down Slope Adjustment
  • AC Frequency Control
  • AC Balance Control
  • Start & End Current Adjustment
  • Pulse Function
  • Pulse Frequency Control
  • Hot Start
  • Arc Force
  • Job Save Function





TECHNICAL SPECIFICATIONS
Input Voltage 1P-230 (+ – 15%) 50/60Hz
Input Current 16 (A)
Current Range TIG 5-200 (A)
Current Range MMA 20-180 (A)
Duty Cycle TIG @ 40°C 200A @ 25%
Duty Cycle MMA @ 40°C 180A @ 25%
Efficiency (%) 80
Power Factor @ 100% 0.73
Protection / Insulation Class IP21/F
Cooling Fan
Dimensions (mm) 590 x 390 × 475
Weight (kg) 22
Conforms to EN IEC 60974-1: 2022 + All: 2022

EN IEC 60974-10: 2021

Approvals BS EN IEC 60974-1: 2022 + All: 2022

BS EN IEC 60974-10: 2021

  • Description
  • Additional information
  • Brand

Description

The CROSARC TIG 400 AC/DC represents the very latest in advanced inverter based power sources operating from a 400v mains supply. This industry leading water cooled machine offers incredible functionality and exceptional welding performance, it is supplied with a transportation trolley and integral water cooling unit as standard. The CROSARC 400 AC/DC incorporates a user friendly control panel allowing the operator full adjustment of all welding parameters, making it the ideal solution for a wide range of industrial and fabrication applications.



Package includes:

  • TIG 400 AC DC Inverter Power Source
  • Parker SGT18FX-12 TIG Welding Torch
  • Earth Return Lead & Clamp
  • Gas Hose
  • Water Cooler
  • Foot Pedal



Options:

  • MMA Lead



Features:

  • Latest IGBT Multi Process Inverter Power Source
  • Digital Volt / Amp Display
  • VRD Safety Device
  • Trolley Mounted
  • Generator Friendly
  • Easy Set Up & Operation



Functions:

  • TIG AC/DC HF/LIFT
  • Pre/Post Flow Gas Adjustment
  • Up/Down Slope Adjustment
  • AC Frequency Control
  • AC Balance Control
  • Start & End Current Adjustment
  • Pulse Function
  • Pulse Frequency Control
  • Hot Start
  • Arc Force
  • Job Save Function





TECHNICAL SPECIFICATIONS
Input Voltage 3P-400 (+ – 15%) 50/60Hz
Input Current 25 (A)
Current Range 10-400 (A)
Duty Cycle @ 40°C 400A @ 60%
Efficiency (%) 85
Power Factor @ 100% 0.93
Protection/ Insulation Class IP23/H
Cooling Fan
Dimensions mm 685 X 295 X 560
Weight (Kg) 40
Conforms to EN IEC 60974-1: 2022 + All: 2022

EN IEC 60974-10: 2021

Approvals BS EN IEC 60974-1: 2022 + All: 2022

BS EN IEC 60974-10: 2021





Additional information

Weight 150 kg

Brand

Cros-Arc
