£495.00 Ex. VAT
- Description
- Additional information
- Brand
Description
-
The R-Tech TIG160PD-D 160Amp DC TIG welder 240V with digital panel and 9 memory store, HF starting, fully featured pulse welding, slope up/down, 2/4 way control, LED display, high 35% duty cycle and remote foot pedal options suitable for welding all steels, Ideal for pipework, fabrication and jobs where fine control is required.
- Professional Ultra Flex Torch – Flexible head and ultra flexible cable & sheath
- Mircostart HF – improved arc starting and less interference – What is this?
- Digital control panel – designed for easy use
- Full 4-way functioning with control of pre/post flow gas, initial/final amps, slope up/down
- Low starting amperage, Ideal for thin and thick materials
- Highly efficient Inverter technology – lightweight and power efficient
- 9 Memory store function – Easily program your jobs into memory
- Amperage Range TIG: 5 to 160 Amps
- Amperage Range MMA: 10 to 130 Amps
- 2 year collect and return UK warranty – What is this?
-
Amperage range 240V DC TIG 5-160A, MMA 10-130A Duty cycle TIG 160A 35% – MMA 130A 35% Input voltage/amps 240v 13A – No load voltage 70v LED Display Shows preset & actual amperage Pulse amperage 5 – 95 % Pulse width 5 – 95 % Pulse frequency 0.5 – 500 Hz Slope up 0 – 25 seconds Slope down 0 – 25 seconds Post flow gas 0 – 25 seconds Pre flow gas 0 – 10 seconds – Ideal for stainless purging HF Start Yes 2T/4T Trigger Yes Memory store Yes – 9 MMA Arc Force Yes 1 -100 % MMA Anti Stick Yes MMA Hot start time 0.1 – 1.5 seconds MMA Hot start amps 1 – 100A Gross weight 14KG Dimensions 425 x 195 x 310 Foot pedal option Yes Insulation class IP21S Cooling fan Yes – Cooling fan with thermostatic protection - Digital control panel – designed for easy use
– Control all parameters from a single button
– Easy start and finish set-up
- 9 Memory store function – Easily program your jobs into memory
- 2 year collect and return UK warranty – What is this?
- Generator Friendly – Generator must be minimum of 5KVA 240V and fitted with AVR (auto voltage regulation)
- Package Includes, R-Tech TIG160PD Digital DC Tig Welder, 4M WP17 Air Cooled Tig Torch, Earth Lead, MMA Lead, Gas Hose, Mains Cable, Argon Regulator, Owners Manual, Torch Consumables Kit including Tungstens
- Digital control panel – designed for easy use
Additional information
Weight 0.15 kg Brand R-Tech
Brand
R-Tech
